What are the types of speed flow meters? Explain their basic principles separately.
[Answer]: There are three types of velocity flow meters: electromagnetic flow meters, turbine flow meters, and ultrasonic flow meters. (1) Electromagnetic flowmeter is an instrument made according to Faradays law of electromagnetic induction to measure the volumetric flow rate of conductive liquids. The volumetric flow rate of the fluid flowing through the pipeline is proportional to the induced electromotive force. (2) Turbine flowmeter is based on the principle of conservation of moment of momentum. The fluid impacts the turbine blades, causing the turbine to rotate. The speed of the turbine changes with the flow rate, and the flow rate value is finally calculated from the speed of the turbine. (3) The principle of ultrasonic flowmeter is to compare the propagation of ultrasonic waves in the fluid when it is flowing with that when it is stationary. Different flow velocities will cause changes in the propagation speed of ultrasonic waves.
2. What are the types of flow meters.
The types of flow meters mainly include the following:
1. Introduction to mechanical flow meters: Flow rates are calculated by measuring the volume of fluid in a pipeline.
. Common types: turbine flowmeter, gear flowmeter, etc. These flow meters typically utilize the mechanical force generated by fluid flow to drive the internal measuring mechanism, thereby achieving a precise measurement of flow rate.2. Introduction to differential pressure flowmeter: It measures the flow rate by measuring the pressure difference generated when the fluid passes through the pipeline.
. Principle: When fluid flows through throttling dev
III. Introduction to Electromagnetic Flowmeters: Using Faradays law of electromagnetic induction to measure flow rate.
. Principle: When a conductive liquid flows through an electromagnetic flowmeter installed in a pipeline, the charged particle family chain in the liquid will generate an induced potential under the action of a magnetic field. This induced potential is proportional to the flow velocity of the fluid, and the flow rate can be calculated by measuring this induced potential.4. Introduction to Ultrasonic Flow Meter: It is a non-contact and non polluting flow meter that uses the propagation speed and inverse distance square relationship of ultrasonic waves to calculate fluid flow velocity. Principle: Ultrasonic flowmeter emits ultrasonic waves into the fluid and receives the reflected ultrasonic signals. Based on the propagation speed and time of the ultrasonic waves in the vertical body of the flow section, the flow velocity of the fluid is calculated to achieve flow measurement.
V. Introduction to Coriolis force flowmeter: Based on Newtons second law F=ma, when a fluid flows in a vibrating pipeline, a Coriolis force proportional to the mass flow rate is generated, and the flow rate is calculated using the Coriolis force.
. Features: The Coriolis flowmeter can not only measure flow rate, but also parameters such as mass, density, and temperature, with high accuracy and versatility. 6、 Introduction to Thermal Mass Flow Meter:
