Introduction to LUGB Vortex Flow Meter

『Vortex flowmeter lu』Related information(clamp on meter|electromagnetic meter|venturi meterrotameter|orifice meter|ultrasonic flow meter|mass flow meter|coriolis mass flow meter|coriolis flow meter|magnetic flow meter|magmeter flow meter|magflow flow meter|mag meter flow meter|electromagnetic flow meter|vortex flow meter|turbine flow meter|thermal mass flow meter|thermal flow meter|rotameter flow meter)

1. Flow range of steam vortex flowmeter

Code: Tongrentqi radial flow range ㎡/h OW-LU-25 DN25 1~10 (liquid) 25~60 (gas) Steam flow rate Please refer to the instruction manual of Yiyanling for details, For DN300 and above, it is recommended to use the plug-in vortex flowmeter OW-LU-32 DN32 1.5~18 (liquid) 15~150 (gas) OW-LU-40 DN40 2.2~27 (liquid) 22.6~150 (gas) OW-LU-50 DN50 4~55 (liquid) 35~350 (gas) OW-LU-80 DN80 9~135 (liquid) 90~900 (gas) OWLU-100 DN100 14~200 (liquid) 140~1400 (gas) OW-LU-150 DN150 32~480 (liquid) 300~3000 (gas) OW-LU-200 DN200 56~800 (liquid) 550~5500 (gas)

2. LUGB type vortex flowmeter Technical parameters

· Measurement medium: a. Zentong liquid: cold water, hot water, various oil products, liquefied petroleum gas, various chemical liquid oils b. Gas: compressed air, oxygen, natural gas, petroleum gas, and various chemical gases c Saturated steam and superheated steam with a temperature below 350 ℃. Possible measurement range: Reynolds number of 5000-700000. Normal operating range: Reynolds number of 20000-700000. Accuracy: ± 1% for liquids; Gas and steam ± 1.5% · Power supply voltage: 24VDC (intrinsically safe flow meters must be powered by safety barriers) · Output signal trace: a. Three wire voltage pulse signal low level: ≤ Hezhoutan 1V; high level: ≥ 5V; duty cycle: about 50% b. Two wire 4-20mA current signal (circuit load ≤ 500 Ω at 24V) · Working pressure

1.6MPa, 2.5MPa, 4.0MPa, 6.3MPa · Pressure loss: △ P=1.079 × 10-6 × ρ× V2, where △ P: pressure loss MPa; V: Flow velocity m/s; ρ: Fluid density Kg/m3 · Sensor material: Stainless steel (304) · Specification: DN1

5、DN20、DN2

5、DN40、DN50、DN6

5、DN80、DN100、DN150、DN200、DN250、DN300· Environmental tem

perature: -40 ℃~+60 ℃ (ordinary type) · Relative humidity: 5%~90% · Protection level: IP65

3. Introduction to LUGB type vortex flowmeter

LUGB type vortex flowmeter is a precision instrument family manufactured based on the Karman vortex principle for measuring the flow of liquid, gas, and steam in sealed pipelines. Due to the sealed detection element inside the detection body, it does not come into contact with the measured medium, and there are no movable parts inside, it does not require on-site maintenance. Therefore, it is highly praised by users and widely used for measurement management and process control in the petroleum, chemical, metallurgical pharmaceutical, thermoelectric, and papermaking industries.

4. Vortex flowmeter Analysis of Several Fault Causes

The common causes of malfunctions in vortex flowmeters mainly include selection problems, parameter tuning errors, secondary instrument failures, connection problems, installation problems, line failures, environmental factors, and debugging problems. The specific analysis is as follows: Improper selection of caliber: After design selection, due to changes in process conditions (such as partial equipment shutdown), the actual flow rate is lower than the original design flow rate, resulting in inaccurate or no indication at small flow rates. For example, the pipeline originally designed for use by multiple devices had a reduced actual flow rate due to the discontinuation of some equipment, and the original selected diameter was too large, resulting in an increase in the lower limit of measurable flow rate. Accuracy cannot be guaranteed at low flow rates. Improvement measures: Combining parameter tuning to improve indication accuracy;
