1. Compact Thermal Mass Flow Meter Installation and Setting Guide

Compact Thermal Mass Flow Meter Installation and Setting Guide

1. Installation Precautions Flow Direction: When installing a flowmeter, be sure to observe the arrow indicating the flow direction on the housing to ensure that the flow direction of air/gas is consistent with the arrow on the housing. This is the foundation for ensuring accurate measurement of flow meters. Requirements for straight pipe section: Although the flowmeter is integrated with a flow regulator and does not require an additional straight pipe section, in order to achieve the best measurement effect, it is recommended to use 3-5 times the inner diameter of the fiber large straight pipe at the inlet. Installation position: The flowmeter can be installed on horizontal or vertical pipelines, and the specific installation position should be determined according to the actual working conditions and pipeline layout. Process connection: For DN

8, DN1

5, DN20, DN25, and DN32 pipelines, G internal thread connection is used. Ensure that the connection is well sealed to prevent gas leakage.

Secondly, the electrical connection flowmeter is equipped with two wiring plugs "A" and "B". By default, it comes with a 5-meter cable with an M8 female connector on one end and an open wire on the other end. For flow meters, a single connecting wire can make them work properly. If it is necessary to separate the output pulse or the power supply and signal separately, two connecting wires need to be ordered.

3. Relevant Settings Download APP: After normal installation and wiring, a dedicated APP needs to be downloaded (Android phones can click on the download link, I

Address of Shaanbei Quality Flow Meter Manufacturer

OS phones can directly search for "S4C-FS" in the app store for download) to configure and calibrate the flowmeter. Scan QR code: Before using the S4C-FS APP to configure or calibrate the flow meter, you need to obtain the flow meter configuration permission by scanning the QR code on the side of the Zhiwang flow meter. Specific operation process: Start the S4C-FS software, and all flow meters that are powered on and not connected to other phones will be displayed on the homepage. For flow meters that have not scanned the QR code, the signal icon is red. On the S4C-FS operating interface, click the scan QR code button. Scan the QR code on the side of the flowmeter head or calibration certificate. After scanning the QR code, the signal icon of the sensor changes from red to green, indicating that the flowmeter is in a read-write state. Once the application scan is successful, the S4C-FS application will always have modification permissions for the flow meter. Set measurement medium: After entering the settings interface, click on the flow rate setting and modify the corresponding measurement medium to read the current real-time standard flow rate (by default, the system will automatically configure the corresponding reference conditions after modifying the measurement medium, without additional changes). The reference conditions for different media under default settings are as follows: compressed air: reference temperature of 20 ℃, reference pressure of 1000hPa. Nitrogen, oxygen, and other industrial gases: reference temperature 0 ℃, reference pressure 1013hPa. Attention: Changing the reference condition settings may result in incorrect measurement results! If you are not familiar with the settings, please contact the te

Address of Shaanbei Quality Flow Meter Manufacturer

1. Compact Thermal Mass Flow Meter Installation and Setting Guide
