Coriolis Flow Meter PDF: Technical Specifications Library for Industrial Automation
Quick Answer: This library gives you real product drawings, signal wiring, meter dimensions, and performance curves for Silver Instruments Coriolis mass flow meters. You can download the PDF pack to check pipe size options from DN15 to DN150, pressure ratings up to PN100, and output options like 4-20 mA HART. Send us your fluid, flow range, pipe size, and process temperature and we will return the exact spec sheet for your application.
Silver Automation Instruments maintains a technical specification library for process engineers, instrument technicians, and procurement teams. The Coriolis flow meter PDF files cover single straight tube and twin curved tube designs. Each file includes installation drawings, wetted material lists, transmitter wiring diagrams, and calibration ranges.
What You Can Download from the PDF Library
Most engineers skip the general brochure and go straight to the specification PDF. The library includes files for standard industrial models with DN sizes from DN15 to DN150. Pressure ratings cover PN16, PN40, PN63, and PN100. Materials cover 316L stainless steel, Hastelloy C22, and titanium. Explosion proof versions have ATEX Zone 1 and IECEx certificates attached.
You will also find wiring schematics for pulse output, RS485 Modbus RTU, and active or passive 4-20 mA loops. This helps a panel builder in Vietnam or a plant engineer in Chile confirm the terminal block before ordering.
Coriolis Flow Meter Parameters We Document
Each technical PDF lists mass flow accuracy, density accuracy, and temperature measurement. For example, the standard model delivers 0.1 percent of rate for liquids and 0.35 percent for gas. Density repeatability is 0.0002 g per cubic centimeter. Temperature measurement uses PT100 and reads from minus 50 to plus 200 degrees Celsius.
The flow range depends on pipe size and fluid. A DN15 Coriolis meter handles 0 to 3000 kilograms per hour for water. A DN50 meter handles 0 to 60000 kilograms per hour. Higher viscosity fluids like glucose syrup or heavy fuel oil need a lower range. The PDF shows pressure drop curves for these cases.
Recommended Models for Common Processes
For a small chemical dosing system, choose the Silver Instruments CMF series with DN15 and 0.1 percent accuracy. The compact transmitter supports 4-20 mA and RS485 at the same time. For a desalination plant feed
Last year a paint manufacturer in Southeast Asia asked us for a Coriolis meter that could handle solvent based fluids with viscosity up to 300 centipoise. We supplied a DN25 twin tube meter with Hastelloy C22. The specification PDF helped their EPC confirm the pressure drop before they placed the order.
How to Use the Technical Specification PDF for Your Project
The fastest way is to enter your pipe size, fluid name, viscosity, flow range, and process temperature in an email. We will return the correct model number and the matching PDF in one business day. You can also send a screenshot of your existing meter nameplate and we will compare it against our library.
Because the PDF files include dimensional drawings, you can forward them to your skid fabricator or piping designer. No need to redraw the meter or guess the flange rating. The wiring diagrams also show the same terminal labels used on the transmitter.
Frequently Asked Questions
What is included in the Coriolis flow meter PDF? The PDF includes product drawings, flange dimensions, wiring diagrams, accuracy curves, pressure drop charts, and material certificates for standard models.
Can I get a PDF for a custom flow range? Yes. Send us your fluid, flow range in kilograms per hour, viscosity in centipoise, pipe size in DN, and process temperature in degrees Celsius. We will return a factory stamped spec sheet.
Do the PDF files cover hazardous area versions? Yes. The library includes ATEX Zone 1 and IECEx versions with explosion proof transmitter housings. The certificate number is listed on the last page of each file.
What output signals can I wire from the Coriolis meter? The standard model has one active 4-20 mA loop, one pulse output, and one RS485 Modbus RTU port. The PDF shows the terminal block layout for each output.
How fast can I receive a quotation? We usually reply within 12 hours if you send the fluid type, flow range, pipe size, pressure, and temperature. Quotes are valid for 30 days.
Contact Silver Automation Instruments for the Coriolis flow meter technical specification library. Tel: +86-135-1213-1526. Whatsapp: 86-135-12131526. WeChat: +86 13512131526.
