Budget Landscape Irrigation Totalizers: Ace Water Flow Meter
Quick Answer: The Ace water flow meter line is a budget totalizer series for landscape irrigation from DN15 to DN50. It gives you total volume reading, pulse output, and optional battery display without a large capital outlay. Send us your pipe size, flow range in m³/h, and output type for a specific quote.
What the Ace Series Covers
Landscape irrigation sites do not need a multicapability flow computer. They need a totalizer that survives daily start and stop cycles, sand, fertilizer residuals, and outdoor temperature swings. The Ace series from Silver Automation Instruments uses a glass reinforced nylon body with brass threads and EPDM seals. It is built for cold water lines up to 50 °C and PN16 pressure.
The meter comes in DN15, DN20, DN25, DN32, DN40, and DN50. The standard register shows total volume in cubic meters. The pulse version emits 10 liters per pulse or 100 liters per pulse depending on the reed switch option. You can connect that pulse to a basic irrigation controller or a data logger.
Common Landscape Irrigation Applications
Most buyers use Ace water flow meters on turf farms, golf courses, public parks, nurseries, and commercial landscaping. In practice, contractors install one meter per zone. That gives them a clear record of how much water went to each block. A turf farm in Queensland ordered 120 units of DN25 Ace totalizers in March 2024. They run on four zones, each flowing 8 to 15 m³/h. The farm manager now compares weekly totals and adjusts pump schedules.
Another example is a hotel landscape team in the Philippines. They installed DN40 Ace meters on two main lines. They saw a 14 percent drop in water use after they began reading totals every Monday. The meters flagged a leaking valve that had gone unnoticed for months.
Outputs and Remote Reading
The basic Ace water flow meter is a mechanical totalizer. It needs no external power. The impeller rotates and the register counts volume. If you want remote reading, choose the pulse output model. The pulse signal works with most irrigation controllers, remote terminal units, and simple relays. Silver Instruments also offers a battery powered LCD totalizer for sites where workers walk the line and record readings by hand.
For SCADA or building management systems, add a 4-20 mA output. That option is available on DN40 and DN50 sizes. The current loop transmits instantaneous flow rate. The pulse signal still gives total volume. Many panel builders use both signals on large commercial sites.
Sizi
Selecting the DN size matters more than the brand. An undersized meter adds pressure drop and can stop at high flow. An oversized meter undercounts at low flow. Here are the practical ranges for landscape water. DN15 suits drip zones up to 3 m³/h. DN25 covers 5 to 12 m³/h. DN40 covers 18 to 35 m³/h. DN50 covers 30 to 60 m³/h. If your zone runs under 1 m³/h, a DN15 unit still records total flow but with reduced accuracy at the very low end.
Because landscape water often contains sand or fine grit, we recommend installing a strainer upstream. The Ace meter body resists sand wear, but the impeller bearing lasts longer when the water is prefiltered. We have seen many customer sites in the Middle East where sand ingress was the main cause of repair.
Pricing and Lead Time
The budget price depends on DN size, output, and quantity. A standard DN25 mechanical totalizer costs between 48 and 70 USD for orders of 10 units. A DN40 pulse output unit costs between 75 and 95 USD. Battery LCD versions add 12 to 18 USD per unit. These are FOB China prices. Freight to Australia, Southeast Asia, the Middle East, and Latin America can be arranged by Silver Instruments.
For a fast quote, call Silver Instruments at +86-135-1213-1526, send a WhatsApp message to 86-135-12131526, or reach us on WeChat at +86 13512131526. Send your pipe size (DN), flow range in m³/h, water source, output type, and estimated annual quantity. We reply within one business day.
Five Key Questions
1. Does the Ace water flow meter work with city water and well water?
Yes. The standard version handles clean city water and well water with small particles. For heavy sand loads, install a strainer upstream.
2. Can I read total volume without power?
Yes. The mechanical register shows total cubic meters. It keeps counting even when the pump is off and no power is available.
3. What pulse rate should I choose for a landscape controller?
Choose 10 liters per pulse for zones under 10 m³/h. Choose 100 liters per pulse for larger lines such as DN40 and DN50. This avoids exceeding the controller input frequency.
4. What is the minimum order quantity?
The minimum order is 10 units for standard sizes. For the first trial order, Silver Instruments can supply 2 or 3 sample units at a slightly higher unit price.
5. How long does delivery take?
Standard DN15 to DN50 Ace meters ship within 5 to 7 working days after payment. Larger orders of 200 units or more may take 15 to 20 working days depending on the pulse output configuration.
