1. What is a volumetric flowmeter? A volumetric flowmeter is an instrument used to measure the total volumetric flow rate of gases and liquids. The basic principle is to continuously fill a measuring chamber with a fixed volume and drive rotating components such as pistons, disks, gears, etc. to perform periodic movements during this process. Whenever the measuring chamber is filled with fluid and discharged once, it means that a certain volume of fluid has passed through the flowmeter. The specific working process is as follows: when the fluid enters the flowmeter, it will push the piston, turntable, or toothed combustion wheel and other components in the measurement chamber to rotate or displace. These rotational or displacement movements of the spinor segments will be recorded by an integrator mechanism. The main function of the accumulator is to accumulate the number of times the measuring chamber is filled and discharged with fluid. Since the volume of the measuring chamber is known, the total volumetric flow rate of the fluid can be obtained by multiplying the number of times by the volume filled in a single time. The advantage of volumetric flowmeter lies in its simple measurement principle, which is not affected by fluid physical properties such as density, viscosity, etc. Therefore, it has high measurement accuracy and stability. Meanwhile, due to the absence of physical quantities that need to be converted during the measurement process, its response speed is relatively fast. In terms of application scenarios, volumetric flow meters are widely used in various situations where gas or liquid flow needs to be measured, such as flow measurement and control in industries such as petroleum, chemical, metallurgy,
2. Types of volumetric flow meters
The types of volumetric flow meters mainly include the following: The principle of volumetric flow meters is to determine the flow rate by measuring the volume of liquid or gas flowing through a pipeline or pipeline per unit time.
. Common types: elliptical gear flow meter, piston flowmeter, waist wheel flowmeter, etc. Features: Suitable for measuring high viscosity liquids, wide range, high measurement accuracy, and installation pipeline conditions have no impact on measurement accuracy. The principle of vortex flowmeter is to measure the flow rate by utilizing the pressure pulsation generated by the rotation of the vortex in the fluid. Features: Suitable for industrial applications with high flow rates, both gases and liquids can be measured, but the requirements for straight pipe sections are relatively high. Vortex flowmeter, due to its measurement principle, can provide stable measurement performance over a wide flow range. Principle of turbine flowmeter: Calculate flow rate by measuring the rotational speed of the turbine in the fluid. Features: It is commonly used for measuring liquids with lower viscosity, with high accuracy and fast response speed. Turbine flow meters have been widely used in liquid flow measurement due to their simple structure and high accuracy in measuring dispersion. The principle of ultrasonic
